Kick Drum Microphone
Transducer: Dynamic (34mm diaphragm)
Polar Pattern: Supercardioid
Frequency Range: 30Hz–12kHz
Sensitivity: -50dB±3dB
Output Impedance: 600Ω

Snare Microphone
Transducer: Condenser (14mm diaphragm)
Polar Pattern: Cardioid
Frequency Range: 30Hz–18kHz
Sensitivity: -40dB±3dB
Output Impedance: 200Ω
Max Sound Pressure Level: 127dB
Signal-to-Noise Ratio: 85dB
Operating Voltage: 48V Phantom Power

Cymbal Condenser Microphone
Transducer: Condenser (16mm diaphragm)
Polar Pattern: Cardioid
Frequency Range: 30Hz–20kHz
Sensitivity: -33dB±3dB
Output Impedance: 200Ω
Maximum Sound Pressure Level: 130dB
Signal-to-Noise Ratio: 88dB
Operating Voltage: 48V Phantom Power
